IPT1500-11 (110/120VAC) 1500W Pure Sine Wave Inverter
| Technical Parameters |
| Continuous Output Power | Surge Power | Power-on Surge Current |
| 1,500W@35℃@Rated input voltage | 3,000W@5S | < 100A |
| Output Voltage | Output Frequency | Output Wave |
| 220VAC (± 3%); 230VAC (-6%–+3%); 240VAC (-9%–+3%) | 50/60Hz ± 0.2% | Pure Sine Wave |
| Output Distortion THD | Load Power Factor | Rated Input Voltage |
| ≤ 3% (Resistive load) | 0.2–1 (Load power ≤ Continuous output power) | 12VDC |
| Input Voltage Range | Rated Output Efficiency | Maximum Output Efficiency |
| 10.8–16.0VDC | > 89.0% | > 93.0% (30% loads) |
| Standby Current | No-Load Current | RS485 Port |
| < 0.2A | < 1.2A | 5VDC/200mA |
| Mechanical Parameters |
| Input Terminal | Dimension (L × W × H) | Mounting Size (L × W) |
| M6 | 387mm × 228mm × 118mm | 361mm × 145mm |
| Mounting Hole Size | Net Weight |
|
| Φ6mm | 6.0kg |
|
| Environment Parameters |
| Working Temperature | Storage Temperature | Relative Humidity |
| -20℃ to +60℃ (Refer to the Derating Curve) | -35 ℃ to +70 ℃ | ≤ 95% (N.C.) |
| Enclosure | Altitude |
|
| IP20 | < 5,000m (> 1,000 meters derating) |
|
| Certification |
| Safety | EMC(Electromagnetic compatibility) | RoHS |
| EN/IEC62109-1, UL458 (Products with 12/24V input voltage support), CSA C22.2#107.1 | EN61000-6-2/EN61000-6-4, FCC 47 CFR Part 15, Subpart A | IEC62321-3-1 |
Highlight
*Pure sine wave output
*Input to output electrical isolation
*Output power factor up to 1
*Input Protection: Low-voltage
*Over-voltage：Output Protection: Overload, Short circuit Overheating
*RS485 com. port to realize remote monitoring
*External switch design, matched with EPEVER products, to expand inverter control function and reduce power consumption
*Diversified AC output sockets
*EN/IEC62109-1/2, EN61000-6-2/4, and FCC approved
Application Scenarios for a 1500W Pure Sine Wave Off-Grid Inverter
A 1500W pure sine wave off-grid inverter is a versatile power solution designed to convert DC (Direct Current) electricity—typically from a battery bank or solar array—into high-quality AC (Alternating Current) power. This makes it an essential component for any independent energy system.
Here are the primary application scenarios where a 1500W inverter excels:
Recreational Vehicles (RVs) and Camper Vans
For those living the "van life" or traveling in RVs, a 1500W inverter is the bridge between your battery bank and household comforts.
- Appliance Powering: It can easily run medium-to-high power appliances such as microwaves, coffee makers, and small refrigerators.
- Entertainment: Provides clean power for flat-screen TVs, sound systems, and gaming consoles without interference.
- Comfort: Capable of powering small air conditioners or electric heaters for short durations, depending on the battery capacity.
Outdoor Adventures and Tailgating
When venturing into the wilderness or enjoying a tailgate party, grid power is unavailable. A 1500W inverter connected to a portable power station or vehicle battery offers freedom.
- Camping: Powers electric grills, portable induction cooktops, and projectors for outdoor movie nights.
- Tailgating: Runs blenders for drinks, electric griddles, and charges camera equipment or drones.
- Tools: Can operate power tools like drills, saws, or small air compressors for remote job sites.
Home Emergency Backup Power
During power outages, a 1500W inverter connected to a deep-cycle battery or a car battery can keep essential systems running.
- Critical Loads: Keeps Wi-Fi routers, modems, and laptops running to maintain communication and internet access.
- Lighting: Powers LED lighting systems throughout the house.
- Medical Devices: The "pure sine wave" output is crucial for sensitive medical equipment like CPAP machines, ensuring they function safely and effectively.
- Refrigeration: Prevents food spoilage by keeping refrigerators and freezers running.
Off-Grid Cabins and Tiny Homes
For permanent off-grid living, a 1500W unit often serves as a secondary or primary inverter for specific circuits.
- Daily Electronics: Charges smartphones, tablets, and laptops.
- Office Equipment: Powers printers, scanners, and monitors for those working remotely from a cabin.
- Kitchen Gadgets: Handles blenders, toasters, and food processors that require stable AC power.
Trucking and Commercial Use
Long-haul truckers and commercial drivers use these inverters to power personal electronics and comfort devices in their cabs.
- Cab Comfort: Powers heated blankets, small microwaves, and coffee makers during rest stops.
- Device Charging: Charges multiple electronic devices simultaneously via AC outlets and USB ports (if equipped).
Important Consideration: Surge Power
While a 1500W inverter provides 1500 watts of continuous power, it typically features a "surge" or "peak" capacity (often 3000W) for a few seconds. This is vital for starting inductive loads like motors, pumps, or compressors found in refrigerators and power tools, which require a burst of energy to start up before settling into a lower running wattage.
