350Wp 110V/120VAC Pure Sine Inverter

[ Time:2026-03-30 ]
  • Details

IPT350-11 (110/120VAC) 350W Pure Sine Wave Inverter


Technical Parameters

Continuous Output Power

350W@35℃@Rated input voltage

Surge Power

700W@5S

Power-on Surge Current

< 30A

Output Voltage

100VAC/110VAC (±3%); 120VAC (-7%–+3%)

Output Frequency

50/60Hz ± 0.2%

Output Wave

Pure Sine Wave

Output Distortion THD

≤ 4% (Resistive load)

Load Power Factor

0.2–1 (Load power ≤ Continuous output power)

Rated Input Voltage

12VDC

Input Voltage Range

10.8–16.0VDC

Rated Output Efficiency

> 87.0%

Maximum Output Efficiency

> 89.0% (70% loads)

Standby Current

< 0.15A

No-Load Current

< 0.8A

RS485 Port

5VDC/200mA

Mechanical Parameters

Input Terminal

M6

Dimension (L × W × H)

229mm × 160mm × 73mm

Mounting Size (L × W)

205mm × 75mm

Mounting Hole Size

Φ5mm

Net Weight

1.5kg


Highlight


Pure sine wave output

Input to output electrical isolation

Output power factor up to 1

Input Protection: Low-voltage, Over-voltage

Output Protection: Overload, Short circuit, Overheating

RS485 com. port to realize remote monitoring

External switch design, matched with EPEVER products, to expand inverter control function and reduce power consumption

Diversified AC output sockets

EN/IEC62109-1/2, EN61000-6-2/4, and FCC approved



Application Scenarios: Powering Every Corner of Your Life

  • RV & Camping Adventures
    In the embrace of nature, the IPT350-11 converts your RV or vehicle's 12V battery power into standard AC electricity. You can safely charge drone batteries, run small车载 (on-board) refrigerators, operate coffee makers, or power laptops, keeping your outdoor life efficient and comfortable.
  • Professional Mobile Office
    For photographers, journalists, and remote workers, stable power is critical. The clean sine wave output protects expensive gear and office equipment from power noise, ensuring data security and stable operation while on the move.
  • Emergency Backup Power
    During home power outages, it can connect to backup batteries to provide emergency power for critical medical devices (like CPAP machines), lighting systems, or communication equipment, safeguarding your family's health and safety.
  • Off-Grid Solar Systems
    As part of a small off-grid setup, it pairs perfectly with solar controllers and battery banks, providing continuous, stable power conversion for remote monitoring equipment, communication base stations, or small household loads.
