＞8000 cycles @80%   DOD(25℃, 0.5C )

•

Metal   Case, excellent heat dissipation, more safety

•

Over   charge, over discharge, over temperature, low temperature, over current and   short circuit protection

•

Certificate:   UN38.3 MSDS IEC62619

•

LCD display screen to monitor cell SOC, voltage, temperature and alarm status

•

Max   4 battery packs can be connected in series/parallel

Electrical   Parameter

Battery Type

LiFePO4

Nominal Voltage (V)

12.8

Nominal Capacity (AH)

314

Energy (WH)

4019

Pack Mode

4S1P

Charge Cut-off Voltage (V)

14.4

Discharge Cut-off Voltage (V)

10.4

Max.Charge Current (A)

200

Max.Discharge Current (A)

200

Recommended Discharge Current(A)

100

Recommend Discharge Depth   (％)

80

Cycle  Life

＞8000 cycles (25°C, 0.5C ) 80% DOD

Communication

RS485

Display

LCD

Mounting

---

Environmental

 Parameter

Charge&Discharge Temperature (℃)

Charge:   0°C~+50°C / Discharge: -20°C~+50°C

Optimal Storage Temperature (℃)

5°C～+35°C

Relative Humidity

40%~80%

Ingress Protection

IP65

Mechanical

Parameter

Terminal

M8

Dimensions (L*W*H)   (mm)

415*220*271

Weight (Kg)

33.4±0.5

Certificate

UN38.3   MSDS IEC62619
