Specificaiton
| Model | MP3043-1020P65 | MP5043-1020P65 | |
| Rated battery voltage | 48VDC | ||
| Battery work voltage range | 42.4VDC to 64.0VDC | ||
| Battery type | Lithium battery/lead-acid battery | ||
| Inverter output | |||
| Continuous output power(@25℃/4H) | 3000W | 5000W | |
| 5S Continuous output power (@25℃) | 6000W | 10000W | |
| Rated output voltage | 220VAC/230VAC/240VAC±5%; 110VAC/115VAC/120VAC±5% | ||
| Rated output frequency | 50Hz/60Hz±0.5Hz | ||
| Output wave | Pure Sine Wave | ||
| Load power factor | 0.2－1(VA ≤ continuous output power) | ||
| Distortion THD | ≤ 5% (Resistive load) | ||
| Max. inverter efficiency | ＞93.6% | ||
| Full load efficiency | ＞90% | ||
| Utility transfer time | ≤10mS | ≤10mS | |
| Inverter to bypass transfer time | ≤1mS | ≤1mS | |
| Utility input | |||
| Utility work voltage range | 170VAC to 285VAC | ||
| Utility input frequency range | 40Hz to 70Hz | ||
| Rated Utility input power | 4500W(@240VAC) | 7500W(@240VAC) | |
| (Charging plus Bypass) | |||
| Utility charging power factor | About 1 | ||
| Max. Utility charging current | 50A | 80A | |
| Solar charging | |||
| Max. PV open circuit voltage | 195V (At minimum operating environment temperature) | ||
| 180V (At 25℃) | |||
| MPPT working voltage | (Battery voltage plus 10V) to 145V | ||
| Max. PV charging power | 5000W (1700W/way) | ||
| Max. PV charging current | 100A (34A/way) | ||
| MPPT tracking efficiency | ≥99.5% | ||
| Charging conversion efficiency | ＞95% | ||
| Temperature compensate coefficient | -3mV/℃/2V (Default) | ||
| Inverter/charger charging current | |||
| Max. inverter/charger charging current | Default 100A (Settable, range 0－100A) | ||
| Others | |||
| No-load consumption | ≤ 48V/ 0.7A | ||
| Model | MP3043-1020P65 | MP5043-1020P65 | |
| Static consumption | ≤ 48V/ 0.15A | ||
| Enclosure | IP65 | ||
| Relative humidity | < 95% (N.C.) | ||
| Altitude | 4000m (If the altitude exceeds 2000 meters, the actual output power is reduced appropriately) | ||
| Work temperature | -20℃ to 55℃ (When the environment temperature exceeds 25℃, the actual output power is reduced appropriately) | ||
| Storage temperature | -40℃ to 60℃ | ||
| Mechanical parameters | |||
| Dimension (Length x Width x Height) | 848mm×435mm×249mm | 935mm×475mm×255mm | |
| Mounting size (Length x Width) | 260mmx160mm | 260mmx160mm | |
| Mounting hole size | Ф10mm | Ф10mm | |
| Net Weight | 52.0kg | 66.0kg | |
*IP65 protection degree
*Applicable for pure on grid/off grid/ backup usage/ self-consumption situation
*Pure sine wave output, with dual voltage (120/240V)
*Integrated UPS module, on/off grid seamless switching under 10ms
*Supports battery mode & non battery mode
*Supports low voltage（48V）lithium /lead-acid battery
*Adjustable charge/discharge currents
*Parallel operation in single-phase or three-phase for 6 units in standard application
*Comprehensive electronic protection guarantees safer and stable operation
*Historical data storage capacity: 25000 records
*Smart monitoring, optional WiFi/4G/Bluetooth remote monitoring
